Continental Hydraulic DR5-12X250RL DR5 5/8″ 100R5 High Temp Hose 250 FT

Description

Continental Hydraulic (510) (510)

DR5 5/8″ 100R5 High Temp Hose 250 FT

Desert DR5 is a high-temperature, medium-pressure hose for use in applications including turbocharger oil lines, tilt cab cylinder and air brake lines, transmission coolant and filtration lines. It is compatible with petroleum oil and phosphate esterbased hydraulic fluids, air, water, diesel fuel, petroleum-based lubricating oils and coolants.

• Outer: Blue Impregnated Textile Braid. Inner: Chlorinated Polyethylene
• Reinforcement: 1 Layer; Braided; Steel Wire
• Maximum Working Pressure: 1500 PSI. Minimum Burst Pressure: 6000 PSI
• Specifications: SAE 100R5 DOT FMVSS 106 Type AII SAE J1402 Type AII
• Temperature Range: SAE 100R5 hydraulic applications: -40C to 150C, Air brake and general air applications: -40C to 93C, General hot oil applications: -40C to 150C, Water applications: -40C to 100C / SAE 100R5 hydraulic applications: -40F to 302F, Air brake and general air applications: -40F to 200F, General hot oil applications: -40F to 302F, Water applications: -40F to 212F

Specifications

Height10.0″Length10.0″Width10.0″
